Heat Transfer Printing Machine for Switch Plate
Product Details:
X
Product Description
Technical Specification
| Parameters | Units | DM 18 |
| Power Consumption | KW | 3 |
| Stamping Temp (Range) | ⁰C | 30 - 350 |
| Printing Pressure | Kgf | 200 |
| Printing Dimension (Round) | inch | 18"Ø x 10"H |
| Printing Dimension (Flat) | inch | NA |
| Linear Printing Speed | inch/s | 4 |
| Printing Output** | pcs/min | At Actuals |
| Power Requirement |
| 230V; 1Ø; 50Hz |
| Machine Dimension (L x B x H) | inch | 52 x 52 x 78 |
| Package Dimension (L x B x H) | inch | 58 x 58 x 86 |
| Net Weight | Kg | 520 |
| Gross Weight | Kg | 760 |
